DECAL-SELF ADHESIVE VINYL
PVC film, dusted calendered, manufactured with monomeric resins. Durability – Indoor 5 years, Outdoor 3 years. Permanent UV Adhesive. Excellent printing quality and stability to solvents. Especially design for printing and applications on flat surfaces e.g. Outdoors, flat surfaces of Vehicles, etc.
Additional Information
Specification
Application
Additional Information
Self Adhesive Vinyl (CV3001G/ CV3003G)
| Inspection Item | Inspection Method | Acceptable Quality Level | Inspection Result | ||||||||
| PVC Weights | Electronic Scale | 130±5gsm | 128gsm | ||||||||
| Glue model | Visual Inspection | Solvent pressure sensitive adhesive | Solvent pressure sensitive adhesive | ||||||||
| Glue Thickness | Thickness gauge | 18±2um | 17um | ||||||||
| Paper Weights | Electronic Scale | 140±10gsm White Paper | 138gsm | ||||||||
| Total Weights | Electronic Scale | 290±10gsm | 294gsm | ||||||||
| Width | Tape Measure | Agreed Size (±2mm) | Qualified | ||||||||
| Length | Tape Measure | 50m (±20mm) | 50m | ||||||||
| Adhesive stripping quality | Peel off | Easy to peel off | Qualified | ||||||||
| Initial adhesion | Primary Adhesive Tester | ≥7# Rolling Ball | 7# | ||||||||
| Permanent Adhesion | Lasting Adhesive Tester | ≥24Hr | 29Hr | ||||||||
| 180° Peel off | Electronic tensile test machine | ≥8N | 10.02N | ||||||||
| Adhesive Test | Fold the adhesive tape | Do not lose glue within 7 times | Qualified | ||||||||
| Appearance test | Visual Inspection | No surface flaw (chute,crumple,water spots,yellow spot,mosquito,crease,galling etc) | Qualified | ||||||||
| Property | Smooth Product, no crumple in 5 meters | Qualified | |||||||||
| Print Effect | Eco-solvent ink printing, 300% of the amount of ink output, no heap ink. | Qualified | |||||||||
| Test Result | Qualified | ||||||||||
Specification
PRODUCT FEATURES
Finish: Matt, Glossy, White Back & Grey Back
Thickness (PVC): 100 microns
Width: 0.92 /1.07/1.27 /1.37/1.52 meters
Length: 50 meters (167 feet)
Application
DECAL-PREMIUM SELF ADHESIVE VINYL
